Portable 10kW Open Type Generator
Portable 10kW Open Type Generator
Portable open type diesel generator with 10kW output, compact structure and stable performance, suitable for light industrial and backup power applications.
PARAMETER
| Model | OW15000E | |
| Generator | Frequency(Hz) | 50/60 |
| Rated output (kW) | 10.0 | |
| Max. output (kW) | 10.5 | |
| Rated AC votage (V) | Voltage Configurable To Meet Different Country Requirements | |
| Power factor (cosФ) | 1/0.8 | |
| DC output (V/A) | 12/8.3 | |
| Phase | Single-Phase / Three-Phase Switchable | |
| Alternator type | Sellf-Excited | |
| Starting system | Electric | |
| Noise level (at 7m)(dB) | 80-85 | |
| Fuel tank capacity(L) | 25 | |
| Continuous work (hr) | 7.0 | |
| Engine | Engine type | Single-Cylinder,Vertical,4-Stroke,Air-Cooled Diesel Engine |
| Bore x stroke (mm) | 105×88 | |
| Displacement (cc) | 761 | |
| Fuel | 0# Or -10# Light Diesel Oil | |
| Lubrication oill volume (L) | 2.2 | |
| Combustion system | Direct Injection | |
| Dimensions | Dimension (LxWxH)(mm) | 930x580x720 |
| Gross weight(kg) | 172 | |
| 20GP/40HQ | 66 / 135 | |
| Standard Features | Voltmeter | Yes |
| AC Output Socket | 2 | |
| AC circuit breaker | Yes | |
| Oil warning light | Yes | |
| Oil alert | Yes | |
| Optional Features | DC circuit breaker | Optional |
| Calculagraph | Optional | |
| Big Wheel | Optional | |
| Three phase voltage | Optional | |
| Current meter | Optional | |
| ATS | Optional | |
| Remote control | Optional | |
| Welding | Optional | |
